Carplay installation tutorial on Audi Q2

Carplay installation tutorial on Audi Q2

apple carplay audi q2

We will see here in pictures how to install Apple Carplay on an Audi Q2. Tutorial also valid for Audi A3, A4, A5, A6, A7, Q5, Q7.

Necessary material: a screwdriver or ratchet with bit 8.

Installation time: 20-30 minutes

Inventory: Carplay module and wiring.
This includes the module, a wifi antenna, 2 LVDS (video) cables, the power cable, the auxiliary cable, and a USB cable (no need to plug it in if using the wireless device).

STEP 1: DISASSEMBLING THE GLOVE BOX

démontage boite à gant audi q2 a3 a4 a5 a6 q3 q5 q7 q8

démontage boite à gant audi q2 a3 a4 a5 a6 q3 q5 q7 q8

Remove the cover with a spatula.

démontage boite à gant audi q2 a3 a4 a5 a6 q3 q5 q7 q8

One screw to remove.

démontage boite à gant audi q2 a3 a4 a5 a6 q3 q5 q7 q8

3 screws at the top.

démontage boite à gant audi q2 a3 a4 a5 a6 q3 q5 q7 q8

2 screws at the bottom of the glove box

démontage boite à gant audi q2 a3 a4 a5 a6 q3 q5 q7 q8

Now remove the unit with the SD card(s) from the glove box using 2 extraction keys.

démontage boite à gant audi q2 a3 a4 a5 a6 q3 q5 q7 q8

Remove the case.

démontage boite à gant audi q2 a3 a4 a5 a6 q3 q5 q7 q8

And unplug the connectors.

démontage boite à gant audi q2 a3 a4 a5 a6 q3 q5 q7 q8

The glove box is now disassembled. We now move on to the connection.

STEP 2: CONNECTION

apple carplay audi q2

The connection is very simple. 2 video cables and a power outlet.

apple carplay audi q2

Pull it up.

STEP 3: TEST

apple carplay audi q2

Press BACK 3 seconds to display the menu.

apple carplay audi q2

We chose Apple Carplay which will launch by default (without the previous menu), to choose Android Auto for example, go to the AUDI application.
