Carplay installation tutorial on BMW F20 with NBT system

Carplay installation tutorial on BMW F20 with NBT system

intérieur bmw f20

We will see here in pictures how Apple Carplay is installed on a BMW 1 series F20 with NBT system.

Required hardware: a T20 torx screwdriver.

Installation time: 30-40 minutes

Inventory: Carplay module and wiring.
This includes the module, a wifi antenna, 2 LVDS (video) cables, the power cable, the auxiliary cable, and a USB cable (no need to plug it in if using the wireless device).

STEP 1: REMOVING THE CAR RADIO

démontage de l'écran bmw série 1

Pull the ventilation grill to the sides, no screws.

panel de climatisation bmw

Now you have to unscrew the air-conditioning control that "hides" the car radio: 2 Torx screws.

module climatisation bmw f20

Now remove the ventilation control (easily).

démontage autoradio bmw f20

Once the air-conditioning front panel has been removed, you can finally see the car radio held in place by 2 T20 torx screws.

démonter autoradio bmw f20

You can now remove the car radio from its housing.

STEP 2: REMOVING THE SCREEN

démontage écran bmw f20

The screen is held by 2 Torx screws (red arrows).

démonter écran bmw f20

To take the screen out, it's very simple, just pull it up.

câble vidéo écran bmw f20

Remove the LVDS (video) cable from the purple connector.

STEP 3: CONNECTION

débrancher câble vidéo bmw f20

Connect the LVDS cable to the display and to the module as follows.

module carplay bmw f20

Connect the purple screen connector (LVDS 2 connector) here.

débrancher autoradio gps bmw f20

Remove the power plug from the radio.

fibre optique bmw f20

Take the fiber optic cable (if you have it) out of your original socket and put it back into the Carplay's power socket (the by-pass).

branchement carplay bmw f20

and finally connect the power bypass of the car radio.

STEP 4: TEST

Press the BACK button for 3 seconds on your iDRIVE wheel.

The menu appears, select what you want to use : Apple Carplay, Android Auto or Mirror Link.

apple Carplay bmw f20

Here we have chosen the Apple Carplay on the BMW 1 Series F20.
