We will see here in pictures how to install Apple Carplay on a BMW F31.

Required equipment: a T20 torx screwdriver.

Installation time: 30-40 minutes

Inventory: Carplay module and wiring.
So we count the module, a wifi antenna, 2 LVDS (video) cables, the power cable, the auxiliary cable, and a USB cable (no need to connect it if we use the device wirelessly).


carplay bmw f30

Pull the stick towards you, it's solid so there is no risk of breaking!

carplay bmw f30

Then, it is necessary to unscrew the air conditioning control which "hides" the car radio.

carplay BMW F30 F31

Simple T20 torx screws to remove.

BMW carplay F30 F31

Remove the cover on the underside of the air conditioning control to see the 2 remaining screws. Removes easily.

BMW carplay F30 F31

BMW carplay F30 F31

Once the front of the air conditioning removed, we can finally see the car radio maintained by 4 screws torx T20.


demontage ecran bmw f30 f31

The screen is maintained by 2 Torx screws (red arrows). To remove the screen, it is very simple, pull it up.


débrancher câble vidéo bmw f20

Then connect the LVDS cable to the display and to the module as follows.

module carplay bmw f20

Connect the purple plug of the display here (LVDS 2 connector).

débrancher autoradio gps bmw f20

Remove the power plug from the car radio, also called QUADLOCK.

fibre optique bmw f20

Take the fiber optic cable (if you have it) out of your original socket, and put it back into the power socket (the bypass) of Carplay.

branchement carplay bmw f20

and finally connect the power bypass of the car radio to finally close the circuit.


Press the MENU button for 3 seconds on your BMW F31 iDRIVE wheel.

The menu will appear, select what you want to use: Apple Carplay, Android Auto or Mirror Screen.

apple carplay bmw f30 f31

We have chosen Apple Carplay which will launch by default (without the previous menu), to choose Android Auto for example, go to the BMW application.

Our module: Apple Carplay for BMW HERE
