Carplay installation tutorial on BMW X6 F16

Carplay installation tutorial on BMW X6 F16

interior f16 x6

We will see here in pictures how to install Apple Carplay on a BMW X6 F16 with NBT system

Required equipment: a T20 torx screwdriver.

Installation time: 30-40 minutes

Inventory: Carplay module and wiring.
So we count the module, a wifi antenna, 2 LVDS (video) cables, the power cable, the auxiliary cable, and a USB cable (no need to plug it if you use the device wirelessly).


démontage cache bmw x5 f15

First, pull the stick towards you, it is solid so there is no risk of breaking!

démontage bmw x5 f15

débrancher connecteur bmw x5 f15

Next, disconnect the connectors at the "warning" button and the START STOP button.

vis cache autoradio bmw f15 x5

Now, it is necessary to unscrew the air conditioning control which "hides" the car radio: 2 Torx screws.

dévisser bmw f15 x5

cache commande ventilation bmw f15 x5

Now remove the ventilation control (easily).

vis autoradio bmw f15 x5

Once the front of the air conditioning removed, we can finally see the car radio maintained by 4 screws torx T20.


démontage écran bmw x5 f15

The screen is maintained by 2 Torx screws (red arrows). To remove the screen, it is very simple, pull it up.

connecteur vidéo écran bmw x5 f15

Pull the LVDS (video) cable out of the pink connector.


carplay bmw f30 f31

Pull the LVDS (video) cable out of the purple connector.

module branchement x4

Connect the purple plug coming from the screen here (LVDS 2 connector) and the plug going into LVDS1 goes directly to the screen instead of the original video cable.

branchement carplay x4

Remove the power plug from the car radio (Quadlock).

branchement carplay x4

Don't forget to put the fiber optic cable back into the Carplay's power socket (the bypass), because without this, there will be no sound!

branchement carplay x4

and finally connect the power bypass of the car radio.


Finally, press the BACK button for 3 seconds on your iDRIVE wheel.

The menu will appear, select what you want to use: Apple Carplay, Android Auto or Mirror Screen.

android auto bmw x5 f15

view of Android Auto on the BMW X6 F16

apple carplay bmw x5 f15

Apple Carplay view on the BMW X6 F16
