Carplay installation tutorial on a Dodge Challenger SRT

We will see here in pictures how to install Apple Carplay on a Dodge Challenger SRT

Required hardware: a T20 torx and Phillips screwdriver.

Installation time: 2-3 hours.

Inventory: 1 Carplay module, 1 electronic circuit, wiring.
So we count 1 module, 1 electronic board, flexible tablecloths, a wifi antenna, 2 LVDS (video) cables, the power cable, the auxiliary cable, and a USB cable (no need to plug it if you use the device wirelessly).

STEP 1: DISASSEMBLE THE CAR RADIO

For example, use a plastic spatula to leverage the plastic spacer.

You can now remove the set.

STEP 2: REMOVAL OF THE SCREEN

4 screws hold the screen.

STEP 3: CONNECTION

Carefully pull out the screen and unplug all the connectors on the back.

Install the tablecloth and the printed circuit in the screen. Video on demand.

STEP 4: TEST

Press the button behind your steering wheel or press and hold directly on the touch screen.

The menu appears, select what you want to use: Apple Carplay, Android Auto or Mirror Screen.

We chose Apple Carplay which will launch by default (without the previous menu), to choose Android Auto for example or even Mirror Link.
