Carplay installation tutorial for Mercedes C-Class (C63 AMG)

Carplay installation tutorial for Mercedes C-Class W205 (C63 AMG)

Apple Carplay Mercedes C63 AMG

We will see here in pictures how Apple Carplay is installed on a Mercedes C63 AMG Class.

Required hardware: a T20 torx screwdriver.

Installation time: 30-40 minutes

Inventory: Carplay module and wiring.
This includes the module, a wifi antenna, 2 LVDS (video) cables, the power cable, the auxiliary cable, and a USB cable (no need to plug it in if using the wireless device).

STEP 1: REMOVING THE DASHBOARD

Apple Carplay Mercedes

First of all, start with the opening button, clipped firmly, use a spatula or a thin object to pry it open.

apple carplay mercedes c63 amg

2 screws to be removed

Apple Carplay Mercedes

Apple Carplay Mercedes

The dashboard is no longer fixed anywhere, just move it.

apple carplay mercedes c63 amg

Pull it up

Apple Carplay Mercedes

Then put the dashboard to one side so as not to interfere, no need to unplug the connectors.

STEP 2: REMOVING THE CAR RADIO

apple carplay mercedes c63 amg

Remove the 2 screws

apple carplay mercedes c63 amg

Remove the power connector (called Quadlock).

STEP 3: CONNECTION

apple carplay mercedes c63 amg

Connect the Quadlock with the By-Pass.

apple carplay mercedes c63 amg

Connect the 2 video cables (LCD-LVDS)

apple carplay mercedes c63 amg

Connect the Wifi antenna

apple carplay mercedes c63 amg

Connect the pink LVDS cable to the blue connector (DISP- as Display).

STEP 4: TEST

carplay mercedes c63

Press the RETURN button on your pad for 3 seconds.

The menu appears, select what you want to use : Apple Carplay, Android Auto or Mirror Screen.

carplay mercedes c63 amg

We chose Apple Carplay which will launch by default (without the previous menu), to choose Android Auto for example, go to the MERCEDES application.
